MCA208M VHF/UHF Receiver Multicoupler - 25 MHz to 1 GHz - 8-ports

MCA208M VHF/UHF Receiver Multicoupler - 25 MHz to 1 GHz - 8-ports

MCA208M is an active multicoupler designed to distribute VHF/UHF antenna signals to eight (8) receivers without loss and with high isolation between ports. It is specifically suited for signal intercept and VHF/UHF monitoring stations, both fixed or mobile platforms. It can be used in any monitoring post using receivers, scanners or spectrum analyzers.

MCA208M has a mechanical and electrical design construction that will meet any government, military or commercial specification. This unit is designed to give high performance results in any radio monitoring post using multiple intercept receivers. Rugged die-cast aluminum enclosure with a black powder coat finish is standard, olive drab green (MIl-841OD) is also available on request.

Now Selling.

8 Port MCA208M VHF/UHF Receiver Multicoupler - 25 MHz to 1 GHz

Options:

(1): EMI/RFI Ceramic feed-thru for DC power hardwired connections.

(2): PCB Conformal coating for high humidity installations.

(3): TNC connectors

(4): N-connector on input port, BNC connectors on outputs (MCA108M/N)

Specifications: MCA208M

Frequency Range: 25 MHz to 1 GHz. 8-Ports

Nominal Impedance: 50 ohm

Port-To-Port isolation (min): 22 dB

Return Loss (all ports): > 20 dB

P1dB = 17 dBm (output) 3OIP = 32 dBm (output

Coupler Gain/Loss: +2 dB to -1 dB (max) over frequency range

RF Connectors: BNC (standard)

Mechanical: 4.75 X 3.75 X 1.50 inches (L.W.H)

Case: Die cast Aluminum, Black powder coating (standard)

DC Power Connector: 2.1/5.5mm coaxial (standard)

DC Power Requirements: +12VDC (nominal) @ 85 mA

Product Code: 02-530558

4 Port MCA204M VHF/UHF Receiver Multicoupler - 25 MHz to 1 GHz

-Broad Frequency Range

-25 MHz Input High-Pass Filter

-No Signal Loss to Output Ports

-Rugged Cast Aluminum Case

Product Code: 02-530557

Specifications: MCA204M

Frequency Range:  25 MHz to 1 GHz  4-Ports

Nominal Impedance:  50 ohm

Port-To-Port isolation (min):  22 dB

Return Loss (all ports):  > 20 dB

P1dB = 17 dBm (output)    3OIP = 32 dBm (output

Coupler Gain/Loss: +2 dB to -1 dB (max) over frequency range

RF Connectors:  BNC (standard)

Mechanical:  4.375 X 2.375 X 1.250 inches (L.W.H)

Case: Die cast Aluminum, Black powder coating (standard)

DC Power Connector:  2.1/5.5mm coaxial (standard)

DC Power Requirements:  +12VDC (nominal) @ 85 mA

time to upgrade to the next model with all the scanners and SDR’s

Selling both.
